Opis produktu
4 tryby pomiaru (moment obrotowy, kąt obrotu, moment obrotowy z kontrolą zmiennego kąta obrotu, kąt obrotu z kontrolą zmiennego momentu obrotowego)
Wyświetlanie elektromechaniczne (z pomiarem elektronicznym) i wyzwalanie (za pomocą znanego mechanicznego „kliknięcia”).
Ocena wizualna złącza śrubowego.
Łatwe dokumentowanie zarejestrowanych pomiarów na komputerze PC poprzez interfejs USB i opcjonalny moduł Bluetooth Low Energy.
Dzięki połączeniu opatentowanego elektromechanicznego wyzwalania z wyświetlaczem i sprzężeniem zwrotnym akustycznym klucz zapewnia sygnalizację o maksymalnej optymalizacji.
Właściwości
electromechanical triggering
acoustic and visual trigger signal
4 measuring modes (torque, angle of rotation, torque with 'angle of rotation' monitoring variable, angle of rotation with 'torque' monitoring variable)
high-resolution colour OLED display and side signal lights
visual evaluation of the bolted joint: yellow light (pre-warning threshold reached), green light (within tolerance range), red light (measurement outside tolerance range)
freely configurable menu structure
battery compartment/battery pack with bayonet connection
optional: Li-ion battery no. 7195-2 and charger no. 7160
3 function modes: triggering (patented electromechanical triggering), peak-hold (indicating mode with peak value display) and track (indicating mode with actual value display)
micro USB interface for data communication
optional Bluetooth low energy-module (5.2)
QuickRelease safety lock - switching system for insert tools
data storage for up to 2,500 processes, including date and time stamp
up to 200 joints in a maximum of 25 guided sequences can be programmed
different tolerance limits adjustable depending on the type of bolted joint
fast and precise setting via the keypad
no unintentional adjustments thanks to password-protected keypad lock
acoustic and visual signal warns of torque wrench overload and forced triggering in clockwise tightening mode
automatic indication of the next calibration date, user-configurable according to elapsed time and/or number of operations
fully automatic calibration and adjustment with the perfectControl® calibration and adjustment device No. 7794-2 (torque) or 7794-3 (torque and angle of rotation) for reducing error influencing factors
units of measurement: N·m, ft·lb, in·lb
automatic extension length correction: when an insert tool with a non-standard extension length is used, input the extension length to ensure that the required target value is achieved
ready for operation again immediately after release
clockwise and anticlockwise tightening - the insert tool must be flipped over for anticlockwise torque in 'triggering' function mode
torque and angle of rotation displays simultaneously
measurement regardless of the force application point (for sizes 1, 2, and 4)
safe handling due to the ergonomically shaped 2-component handle (resistant to the most common oils, greases, fuels, brake fluids and Skydrol)
3 certificates included (torque indicating/triggering in accordance with DIN EN ISO 6789-2:2017, angle of rotation based on VDI/VDE 2648-2)
in sturdy plastic box (sizes 40-100 in steel box)
registered design, patented
supplied with SensoMaster 4 software, USB cable, 4 batteries AAA/LR03, 1.5 V
angle of rotation display resolution 0.1°
angle of rotation accuracy ± 1°, ± 1 digit to 100°, >100° at least 1%, ± 1 digit
torque display resolution ≤ 60 N·m: 0.01 N·m; > 60 N·m: 0.1 N·m; > 400 N·m: 1 N·m
torque accuracy ± 2%, ± 1 digit
